Horizontal grinder/chipper

The Horizontal grinder/chipper is suitable for various materials such as waste packaging boxes, templates, plates, branches, wooden crates, and pallets. The function is more powerful, stable and durable, the material is widely applicable, and the operation is convenient. The comprehensive crusher has a mobile operation mode and a fixed operation mode, which is flexible and changeable to meet the needs of different users.



1. Production introduction:

The Biomass Horizontal grinder/chipper has a wide range of processing materials, such as wood, board, slats, round wood cores, architectural stencils, etc., as well as various non-wood materials such as various straws, cottonwood, and reeds. Wide range of applications. This machine adopts chain plate type intelligent feeding, which can automatically adjust the feeding speed according to the main motor load. It is the ideal equipment for biomass power plants to make the machine run at full load to avoid no-load operation, make the feed smoother and greatly increase production capacity.

Horizontal grinder/chipper

Horizontal grinder/chipper

This model processing raw material is widely, (deployment convenient and flexible, ) can be processed such as all kinds of timber, slab, slat, log core, building templates, etc. And all kinds of non-wood raw materials such as bulk straw wood, cotton, reed, wide application scope.

This machine adopts chain plate intelligent feeding, which can automatically adjust feeding speed machine run full load to avoid idle running, make the feed flow more smoothly and greatly, improve the production capacity.

2. Product specification:

Horizontal grinder/chipper  Type 2000-800 2000-1000 1600-500 1600-700 1600-800 1400-500 1400-700 1250-500 1250-600
Knife roll(flying knife) speed 560 560 560 560 560 560 560 560 560
Knife roller(hammer head) speed 640 640 640 640 640 640 640 640 640
Number of flying knives(pieces) 4 4 3 3 3 4 4 3 3
Number of hammers 32 32 24 28 28 24 24 20 20
Main motor power 315 315 200 315 355 200 250 132 132
Production capacity 45 50 25 30 40 15-20 25 15 15
Inlet size 2000X800 2000X1000 1600X500 1600X700 1600X800 1400X500 1400X700 1250X500 1250X600
Total weight 38 40 24.5 25 33 16 24 14 15

3. Raw material:

Wood slab Bamboo Branch Waste wood board Wood pallet Wood
Wood slab Bamboo Branch Waste wood board Wood pallet Wood
